This commercial grade emergency batten light, measuring 620mm in length, exemplifies the pinnacle of industrial-grade lighting solutions. Designed and manufactured in Australia, this robust luminaire is engineered to provide reliable performance in a range of challenging environments. Operating at an input voltage of 240V AC, the batten light delivers high-output, dedicated LED illumination, offering 130 lumens per watt. This ensures superior brightness, essential for maintaining a safe and productive work environment, even in areas with low ambient light. Its practical design guarantees swift and hassle-free installation, maximizing efficiency from the moment it is deployed.
The lighting unit features an innovative half-power switch on the driver, which provides precise control over its output. By reducing the lumen output by 50% when necessary, it offers flexibility in energy consumption without compromising on performance. Additionally, the switchable colour temperature (CCT) feature offers three options—3000K, 4000K, and 5000K—enabling the user to tailor the lighting to specific needs. Whether warmth is required for creating a welcoming atmosphere or daylight white for high-visibility tasks, this batten light caters to diverse industrial applications. The opal diffuser enhances light distribution, ensuring uniformity and contributing to improved safety by eliminating harsh shadows.
Designed with durability in mind, this luminaire complies with Australian standards AS2293.3, AMD 1 & 2 Annex C, and EMC regulations, ensuring both safety and performance. The emergency function is supported by a lithium iron phosphate (LiFePO4) battery, offering a runtime of over 90 minutes in accordance with Australian emergency lighting requirements. The 7.5W and 15W wattage options, enabled by the half-power switch, further enhance its efficiency, making it ideal for both maintained and non-maintained configurations. The durable construction, coupled with a 5-year warranty on the body and a 3-year warranty on the battery, underscores the product’s long-term reliability and resilience.
The emergency batten light is housed in a combination of high-quality metal and polycarbonate materials, providing both strength and corrosion resistance. It is fitted with wire guards for added protection, ensuring that the light remains intact even in demanding environments. The opal cover not only promotes even light output but also contributes to the overall durability of the unit. The unit is equipped with a large PA16 terminal for easy connection, and it features 20mm knockouts for conduit or cable glands, providing further flexibility during installation. With a beam angle of 120° and a colour rendering index (CRI) greater than 80, the batten light is optimized to deliver high-quality, efficient lighting across a variety of industrial settings.
COLOUR: White
WARRANTY: 5 year warranty / 3 year warranty on battery
IP RATING: IP20
MATERIAL: Metal and polycarbonate and opal diffuser
LUMENS: 130 lm/W high output dedicated LED
COLOUR TEMP: CCT - 3000K (warm white) / 4000K (cool white) / 5000K (daylight white) - switchable
GLOBE TYPE: LED (fixed in fitting)
GLOBE INCLUDED: Yes (fixed LED chip)
CRI: >80
BEAM ANGLE: 120°
DIMMABLE: No
DIMENSIONS: 620mm L x 109mm W x 82mm H
WATTAGE: 7.5W / 15W (half power switch on the driver which decreases the lumen output by 50%)
VOLTAGE: 240V
APPROVAL: Complies with AS2293.3 AMD 1 & 2 Annex C / EMC compliant
DURATION: Emergency duration >90 minutes (per Australian standards)
EMERGENCY: Maintained / Non-Maintained
BATTERY: LiFePO4
DESIGNED: Australian
COVER: Wire guards, opal with even light output
TERMINAL: Large terminal, PA16
FEATURE: 20mm knockouts for conduit or cable glands, Charge time 24 Hours
MODE: Usually non-maintained (but can be wired to maintained by the installing electrician)
